Deep RayCast3D C++

Overview

DeepRayCast3D is a custom Godot GDExtension plugin that enhances the functionality of the built-in RayCast3D.
Unlike the default node, this extension allows multiple consecutive collision detections along a single ray beam, making it ideal for complex scanning, sensors, weapons, or physics analysis.

It also includes a fully customizable visible beam renderer, enabling visual debugging and in-game effects.

Features

Detect multiple colliders along a single ray.
Works with both PhysicsBody3D and Area3D.
Configurable detection distance, margin, and collision mask.
Optional visible beam with customizable color, opacity, emission, and geometry.
Supports automatic forward projection or manual targeting using to_path.
Emits a signal when collisions are detected with detailed hit information.

Installation

Download or clone the repository from GitHub.

Copy the folder:

addons/deep_raycast_3d

into your Godot project directory under:

res://addons/

Resulting in:

res://addons/deep_raycast_3d/

Open your project in Godot, and ensure the plugin is recognized.
The plugin file deep_raycast_3d.gdextension will automatically register the custom nodes.

Note: When exporting your game, ensure that the option “Extension Support” is enabled in the export settings.

Node Overview

`DeepRayCast3D`

An advanced raycasting node with multiple collision checks per beam.

`DeepRayCast3DResult`

Holds information about a single hit detected by DeepRayCast3D.

Example — Iterating Colliders in `_physics_process`

@onready var deep_ray = $DeepRayCast3D

func _physics_process(_delta):
    # Perform multi-hit detection
    for i in range(deep_ray.get_collider_count()):
        var collider = deep_ray.get_collider(i)
        var position = deep_ray.get_position(i)
        var normal = deep_ray.get_normal(i)
        print("Hit:", collider, "at", position, "normal:", normal)

Example — Using Signals

func _ready():
    var deep_ray = DeepRayCast3D.new()
    deep_ray.enabled = true
    deep_ray.forward_distance = 20.0
    deep_ray.max_result = 5
    deep_ray.collide_with_bodies = true
    deep_ray.collide_with_areas = false
    add_child(deep_ray)

    deep_ray.cast_collider.connect(_on_ray_hits)

func _on_ray_hits(results):
    for result in results:
        print("Detected:", result.get_collider(), "at", result.get_position())

Key Properties

Property	Type	Default	Description
`activate_emission`	`bool`	`true`	Enables emission lighting on the beam using the configured `color`. When disabled, the beam is rendered as unlit.
`auto_forward`	`bool`	`true`	Automatically casts along the parent’s -Z axis. When disabled, the beam follows the target defined in `to_path`.
`collide_with_areas`	`bool`	`false`	Enables detection of `Area3D` nodes.
`collide_with_bodies`	`bool`	`true`	Enables detection of `PhysicsBody3D` nodes.
`collision_mask`	`int`	`1`	Physics collision mask determining which layers the ray interacts with.
`color`	`Color`	`Color(1, 0, 0, 1)`	Base color of the visible beam and its emission.
`emission_energy`	`float`	`10.0`	Controls the intensity of the beam’s emission when `activate_emission` is true.
`enabled`	`bool`	`true`	Enables or disables the raycast. When false, no collision checks are performed.
`exclude_parent`	`bool`	`true`	Automatically excludes the parent node from collisions to prevent self-hits.
`forward_distance`	`float`	`10.0`	Maximum beam distance when `auto_forward` is enabled.
`hit_back_faces`	`bool`	`true`	Determines whether back faces of surfaces can be hit by the ray.
`hit_from_inside`	`bool`	`true`	Allows detection even if the ray starts inside a collider.
`layers`	`int`	`1`	Rendering layer mask for the visible beam (does not affect physics).
`margin`	`float`	`0.01`	Small offset applied after each hit to avoid detecting the same collider repeatedly.
`max_result`	`int`	`10`	Maximum number of consecutive collisions detected per cast.
`opacity`	`float`	`0.7`	Transparency level of the beam (0 = invisible, 1 = opaque).
`position_offset`	`Vector3`	`Vector3(0, 0, 0)`	Offset applied to the beam’s origin relative to its parent node.
`radius`	`float`	`0.02`	Radius of the beam’s cylindrical mesh.
`raycast_visible`	`bool`	`true`	Makes the beam visible in the viewport; disable for logic-only usage.
`rings`	`int`	`4`	Number of vertical ring divisions in the beam’s cylinder.
`segments`	`int`	`64`	Number of radial subdivisions (sides) in the beam’s cylinder mesh.
`to_path`	`NodePath`	`""`	Target node path used when `auto_forward` is disabled. The beam is cast toward this node.

Methods

Method	Return Type	Parameters	Description
`add_exclude(value)`	`void`	`value: PhysicsBody3D`	Adds a physics body to the exclusion list. Bodies in this list are ignored during raycast checks. Useful for preventing the ray from hitting its own emitter.
`clear_exclude()`	`void`	—	Clears the exclusion list, allowing all bodies to be detected again.
`get_collider(value)`	`PhysicsBody3D`	`value: int`	Returns the physics body corresponding to the given hit index from the last deep raycast result. The index must be between `0` and `get_collider_count() - 1`.
`get_collider_count()`	`int`	—	Returns the number of colliders detected in the last deep raycast execution.
`get_normal(value)`	`Vector3`	`value: int`	Returns the surface normal vector of the collision at the given hit index. This vector represents the perpendicular direction to the impacted surface.
`get_position(value)`	`Vector3`	`value: int`	Returns the global position of the collision point for the specified hit index.
`remove_exclude(value)`	`void`	`value: PhysicsBody3D`	Removes a specific body from the exclusion list, allowing it to be detected again.

Result Object (`DeepRayCast3DResult`)

Method	Description
`get_collider()`	Returns the collider object.
`get_position()`	Returns the hit position in world space.
`get_normal()`	Returns the hit surface normal.
`get_face_index()`	Returns the mesh face index hit.
`get_rid()`	Returns the RID of the hit object.
`get_shape()`	Returns the shape index of the hit.

Screenshots

Screenshot InputManager

Screenshot 1

Screenshot 2

❤️ Support

If this project helps you, consider supporting:
https://github.com/sponsors/Saulo-de-Souza
https://www.paypal.com/donate/?hosted_button_id=G24W4KL9ALH64

Changelog for version 1.0.0

No changelog provided for this version.

Reviews (0)

Deep RayCast 3D Cpp has no reviews yet.

Deep RayCast 3D Cpp

by Saulo Souza

DeepRayCast3D is a powerful plugin for Godot Engine 4x that allows you to perform deep raycasts, passing through multiple objects in a straight line and recording all collisions along the way. It is ideal for shooting systems, obstacle detection, chain interactions, laser effects, and much more. Now in C++ for higher performance, but if you want an easier installation, install DeepRayCast3D in gdscript here: https://store-beta.godotengine.org/asset/saulo-souza/deep-raycast-3d/

Reviews: No reviews

License: MIT

Source: View source code

Last updated: 14 February 2026
